AQUILA 48 A Smart Level 2 Home EV Charger, 11.5 kW, Wi-Fi

  • 11.5 kW at 48 A, hardwired
  • 25 ft SAE J1772 cable with holster
  • Wi-Fi, Bluetooth and the eMÖTEN app, free on MÖTEN chargers
  • Scheduling for off-peak rates
  • OCPP 1.6, 2.0.1 ready
  • ETL certified (UL 2594), FCC; 2-year warranty

Out of stock

SKU: AQUILA-48S Category:
Description

Description

AQUILA is the smart 48 A home charger: 11.5 kW of Level 2 power with Wi-Fi, Bluetooth and the eMÖTEN app for scheduling and charging history.

Who it is for

Most EV owners who want app control and off-peak scheduling without the panel capacity an 80 A charger needs.

Smart features

Use the eMÖTEN app to start and stop sessions, schedule charging when electricity costs less and review every session. RFID access control is built in.

Installation

AQUILA is hardwired on a 208 to 240 V split-phase circuit with a 60 A breaker, and its IP65 enclosure is rated for indoor and outdoor use. A licensed electrician installs it. Look up rebates in your state first.

Current setting (DIP switch)

Set by a qualified electrician to match the circuit. The breaker must be rated for the setting, for example 48 A on a 60 A breaker.

AQUILA DIP switch positions, charging current, power at 240 V and breaker size
Switch Current Power at 240 V Breaker
0 16 A 3.8 kW 20 A
1 32 A 7.7 kW 40 A
2 40 A 9.6 kW 50 A
3 48 A 11.5 kW 60 A

Specifications

Max output 11.5 kW at 48 A
Input 208 to 240 V AC, 50/60 Hz, split-phase
Current setting (DIP switch) 16, 32, 40 or 48 A (switch 0 to 3, on a 20, 40, 50 or 60 A breaker)
Circuit breaker 60 A
Installation Hardwired
Connector SAE J1772 (Type 1); NACS vehicles via adapter, sold separately
Cable 25 ft with holster
Connectivity Wi-Fi, Bluetooth, Ethernet, RFID
Software eMÖTEN app; OCPP 1.6, 2.0.1 ready
Protection Under- and over-voltage, RCD (CCID 20), surge, ground fault, over-current, over-temperature and control pilot fault protection
Certifications ETL certified (UL 2594, UL 2231-1 and UL 2231-2), FCC
Enclosure IP65, IK08; indoor or outdoor, wall-mounted with bracket
Operating temperature -30 to +50 C (-22 to 122 F)
Humidity Up to 95%, non-condensing
Altitude Up to 6,561 ft (2,000 m)
Dimensions 7.1 x 7.1 x 3.7 in; 13.1 lb net (shipping box 17.7 x 17.7 x 6.3 in, 15.5 lb)
Warranty 2-year manufacturer warranty, extendable to 5 years (2 + 3) or 10 years (2 + 8) in total; extended warranty available for purchase. Backed by a 97% uptime SLA.

Download spec sheet (PDF)

2-year manufacturer warranty, extendable to 5 years (2 + 3) or 10 years (2 + 8) in total; extended warranty available for purchase. Backed by a 97% uptime SLA. Sales and support every day, 7 a.m. to midnight Eastern. Free shipping on MÖTEN hardware across the United States.

Frequently asked questions

What circuit does AQUILA need?

AQUILA is hardwired on a 208 to 240 V split-phase circuit with a 60 A breaker, installed by a licensed electrician.

Can I schedule charging for off-peak rates?

Yes. The eMÖTEN app, free on MÖTEN chargers, lets you schedule charging and review your charging history.

Will AQUILA charge a Tesla?

Yes, with a J1772 to NACS adapter, sold separately.

Related: Home EV Chargers · Level 2 vs DC fast: choose by dwell time · NACS vs CCS: which connectors to install · EV charger rebates · Request a quote

Technical Specifications

Technical Specifications

Current: 48 A (11.5 kW) max, Adjustable 16A/32A/40A/48A
Product dimensions: 7.1″ X 7.1″ X 3.7”
Product weight: 13.5 lb
Installation: Hardwired 3-feet Cable Whip
Supply circuit: 208/240 V, 60 A
Charge cable length: 25 ft
Connector: Impact Resistant Rubberized J1772 connector
Holster included: J1772 Wall Mount Connector Holster
Enclosure: IP65 / IK08 for Indoor or Outdoor installation, NEMA TYPE 3R
Operating temperature: -22°F to +122°F (-30°C to +50°C)

Certifications

Certifications

FCC: Date Issued: 06/30/2023 FCC Identifier: 2BA3A-ACEVCN22P3
ETL: Date Issued: April 28.2023 Control / Certificate#: 5005806
Standards: UL2594:2016 Ed.2; CSA C22.2#280:2016 Ed.2

What's In The Box

What's In The Box

  • AQUILA-48S EV Charger with Wall Mount
  • Free eMÖTEN APP for Home use
  • User Manual
  • Connector Holster with Wall Mount
  • Hardware for installation
Warranty

Warranty

3-year limited warranty
