PHOENIX-48S Level 2 EV Charging Station, 11.5 kW/48 Amp, Commercial, Networked

Description

PHOENIX by MÖTEN evfc is a reliable, subscription-free Level 2 charging station for businesses. It offers up to 45 miles of range per hour with a 25 ft charging cable, is compact and durable, and includes Wi-Fi and RFID compatibility. Enjoy 24/7 support and monitoring with no additional network fees. Backed by a three-year warranty in the US and Canada, PHOENIX is your dependable EV charging solution.

SAFETY FIRST: Our chargers meet and exceed North American safety standards, holding Energy Star and UL listings (UL 2594, UL 2231-1/-2). Equipped with features like UVP, OVP, Ground Fault Protection, and more, we prioritize safety.

FASTEST ONBOARDING: Experience quick and easy setup. Our chargers are fully customized—simply connect to power and Wi-Fi to join the eMÖTEN network.

ZERO SOFTWARE SUBSCRIPTION FEES: Save on ongoing costs with MÖTEN EV chargers. Enjoy lifelong access to our eMÖTEN CMS App with no monthly fees. Fully compatible with OCPP 1.6 and 2.0.1 for seamless integration.

24/7 CUSTOMER SERVICE & MONITORING: Our technical experts are available around the clock to resolve any issues with your charger.

HIGHEST UPTIME OF 99% IN THE INDUSTRY: Enjoy a 98.9% uptime rate, the highest in the industry, ensuring reliable charging when you need it.

AVOID EXPENSIVE PANEL UPGRADE WITH e MÖTEN: Use eMÖTEN Dynamic Power Management to install multiple chargers without costly panel upgrades.

GENERATE REVENUE BY ACCEPTING PAYMENTS: Our chargers accept payments, allowing you to set prices and create new income opportunities through the eMÖTEN CMS web application.

TOP FEATURES:

Compact Size: 9.8″ x 13.8″ x 5.1”
Charging Speed: Up to 45 miles/hour (72 km/h)
Adjustable Power: 16A to48A
25-foot cable with connector holster
Type 1 plug, impact-resistant, IP65 / IK08 rated for indoor and outdoor use.

Technical Specifications

Enclosure Material: Plastic (PC+PBT)
Enclosure Rating: NEMA Type 3R
Status Indicator: Power Present, Charging, Fault
Standards And Certifications: UL2594| UL 2231-1| UL 2231-2| UL 2251| UL 62| UL 991| UL 1998| NFPA 70 Article 625| UL840| CSA Std. C22.2#280|
OCPP 1.6 Compliant: Tested and connects to more than 75 OCPP platforms
Current: 80 A (19.2 kW) max, Adjustable 16A/32A/40A/48A/70A/80A
Supply Circuit: 208/240 V, 100 A
Product Dimensions: 13.8″ X 9.8” X 5.1”
Product Weight: 22.5 LBS
Charge Cable Length: 25 ft
Installation: Hardwired 3-feet Cable Whip
Connector: Impact Resistant Rubberized J1772 connector
Enclosure: IP65 / IK08 for Indoor or Outdoor installation, NEMA TYPE 3R
Operating Temperature: -22°F to +122°F (-30°C to +50°C)
Altitude: Up to 6,500 ft. (2,000 m)
Operating Humidity: < 95% Relative Humidity, Non-Condensing

Certifications

Energy Star: Date Issued: November 18, 2022 Control / Certificate#: 5023388
FCC: Date Issued: 11/02/2022 FCC Identifier: 2A2RN-ACEVCN13P2
ETL: Date Issued: Jan 16, 2023 Control / Certificate#: 5005806
Standards: UL2594:2016 Ed.2; CSA C22.2#280:2016 Ed.2
Certified For British Columbia EV Rebates: EV chargers eligible for rebates | Electric Vehicles | BC Hydro
Certified For Quebec EV Rebates: Bornes et câbles de recharge admissibles au programme Roulez vert (quebec.ca)

What’s In The Box

PHOENIX-48S EV Charger with Wall Mount

FREE eMÖTEN CMS and phone App for Life

2 RFID Cards
User manual
Hardware for installation

Warranty

3-year limited warranty
